Top Ranger Series ORB-S

Get a Price/Quote

Top Ranger Series ORB-S Specification

Noise Level
Low

Voltage
220/380 V

Ambient Temperature
-15C to +50C

Features
Corrosion Resistant, Long Service Life, Energy Efficient, Heavy Duty Construction

Standard
IS:8034, IS:9283

Efficacy
Above 80%

Bearing Type
Ball Bearing

Horse Power
0.5 - 12.5 HP

Current Type
AC

Poles Number
2 Pole

Pressure
Max 15 Bar

Cooling Method
Water Cooled

Rated Frequency
50 Hz

Torque
Standard

Power Rating
0.37 - 9.3 kW

Rated Voltage
220 V / 380 V

Starting Type
DOL

Sealed Type
Sealed

Motor Type
Oil Filled, Rewindable

Product Type
Submersible Pump Motor

Output Power
0.5 HP to 12.5 HP

Frequency (MHz)
50 Hz

Protect Feature
Thermal Protection

Phase
Single Phase / Three Phase

Speed
2850 RPM

Power
Up to 9.3 kW

Color
Silver & Black

Dimension (L*W*H)
600 mm x 150 mm x 150 mm

Weight
23 Kg

Shaft Diameter
32 mm

Mounting Type
Vertical

IP Rating
IP 55

Discharge Range
15-650 LPM

Pump Material
Stainless Steel

Max. Immersion Depth
250 m

Rewindable Motor
Yes

Cable Length
Up to 100 m

Application
Irrigation, Domestic, Agriculture, Industrial Water Supply, Commercial Use

Coupling Type
NEMA Standard

Type of Protection
Thermal and Overload

Insulation Class
Class B / F

About Top Ranger Series ORB-S

Specifications

Item / Model	S-050	S-070	S-100	S-120	S-160	S-190	S-240	S-280	S-310	S-380	S-410
Theoretical Displacement (cm³/rev)	54	71.4	96	118.4	163.4	184	235.5	282.5	306.9	376.4	409.9
Max. Revolution (min^-1)	990	930	730	590	440	380	300	250	230	200	180
Normal Continuous Torque (Nm)	110	155	210	250	330	365	395	410	420	465	470
Max. Instantaneous Torque (Nm)	134	183	256	300	375	433	493	483	498	540	554
Normal Continuous Pressure (P MPa)	15.5	15.5	15.5	15.5	14	14	12	10.5	10	9	8.5
Max. Instantaneous Pressure (P MPa)	19	19	19	18.5	17	17	15.5	12.5	12	10.5	10
Permissible Back Pressure (MPa)	7
Radial Load ( N )	6500
Thrust Load ( N )	5000
Approx. Weight (kg)	7.1	7.3	7.5	7.7	8.1	8.3	8.7	9.1	9.3	9.8	10.2

Superior Performance for Multiple Sectors

Designed for varied fields such as agriculture, industry, irrigation, and domestic water supply, the Top Ranger Series ORB-S ensures high output and dependable service. With a maximum discharge of 650 LPM and high immersion depth capability, it meets demanding requirements across commercial and residential usage.

Advanced Protection and Durability

Equipped with both thermal and overload protection, as well as IP55 sealing, this pump resists operational challenges and environmental factors. Its stainless steel construction and stringent IS:8034 and IS:9283 standards provide long-term durability and resistance to corrosion.

Energy Efficiency and Easy Maintenance

Operating with an efficacy above 80%, this pump reduces power consumption effectively. The oil-filled, rewindable motor provides sustained performance and ease of maintenance. Vertical mounting and ball bearing design further optimize operational reliability and lifespan.

FAQs of Top Ranger Series ORB-S:

Q: How can the Top Ranger Series ORB-S pump be installed for different applications?

A: Installation is versatile due to its vertical mounting type and compatibility with NEMA standard couplings. Whether for irrigation, domestic, agricultural, or industrial uses, it can be submerged up to 250 meters and comes with cable lengths up to 100 meters to suit various setups.

Q: What protection features does the ORB-S pump offer for safe operation?

A: The pump includes built-in thermal and overload protection, IP55 sealing, and complies with IS:8034 and IS:9283 standards. These features protect the motor from overheating and excessive load, ensuring reliable operation even in challenging environments.

Q: When should the pumps motor be rewound or maintained?

A: Routine inspection is recommended based on usage intensity. With its rewindable motor and oil-filled design, maintenance is straightforward; scheduled checks every 612 months can help maintain peak performance and extend service life.

Q: Where is the Top Ranger Series ORB-S pump most effectively employed?

A: The ORB-S pump excels in settings such as agricultural fields, irrigation systems, domestic water distribution, commercial establishments, and industrial water supply networks, thanks to its robust build and high-output capabilities.

Q: What is the process for coupling the pump with other equipment?

A: The pump uses NEMA standard couplings, facilitating a seamless connection with compatible motors and equipment. This makes integration into existing setups convenient for users and technicians.

Q: How does the pumps energy efficiency benefit users?

A: With efficacy above 80%, the pump consumes less energy during operation, resulting in lower electricity costs and environmentally friendly performance without sacrificing discharge or pressure capabilities.

Q: What advantages does the stainless steel construction provide?

A: Stainless steel makes the ORB-S pump corrosion-resistant, durable, and suitable for heavy-duty applications, ensuring a longer lifespan even when exposed to harsh or variable water qualities.
