NOP Coolant Unit CT

Get a Price/Quote

NOP Coolant Unit CT Specification

Speed
2800 RPM

Max Suction
2 meters

Control System
Manual Control

Mounting Type
Horizontal

Noise Level
<60 dB

Inlet/Outlet
1/2 inch (BSP)

Flow Rate
15 L/min

Caliber
12 mm

Voltage
220V / 380V

Working Temperature
-10C to +100C

Discharge Pressure
0.1 MPa

Features
Corrosion Resistant, Long Life, Low Maintenance

Theory
Centrifugal Pump

Frequency
50 Hz

Head Size
8 meters

Material
Cast Iron & Stainless Steel

Structure
Single Stage

Power
200W

Standard
ISO 9001:2015

Fuel Type
Electric

Pressure
0.12 MPa

Usage
Coolant Circulation

Application
CNC Machine, Lathe, Milling Machine

Suction Type
Side Suction

Seals Type
Mechanical Seal

Priming
Self Priming

Pump Type
Coolant Pump

Capacity
2L

NOP Coolant Unit CT Trade Information

Main Domestic Market
All India

About NOP Coolant Unit CT

Backed by more the 02 years of dedication, we offer the finest NOP Coolant Unit YTH Pumps to clients. Made up of top-notch stainless steel and other basic material, this is acknowledge for hassle-free functionality, less maintenance needs, wear & tear resistance and long lasting nature. We offer the NOP Coolant Unit YTH Pumps in varied weights, capacity and other specifications at moderate rates. In addition, we deliver these pumps in protective packaging to clients within promised time frame.

Salient Features :

Pump: Trochoid^TM
Motor: 750~1500 W/AC
Flow rate: 12~28.8 /min
Maximum Pressure: 2.0 MPa

Double-cyclone filter

Two layers of double cyclones (one large cyclone and six small cyclones) remove chips from the coolant fluid.

Trochoid^TM pump/ 2.0 MPa, 1.5 MPa

1.5A rotor turning in a trochoidal curve generates pressure to suck and discharge fluid. This is an extremely efficient self-priming pump.

Compatible with the TAZUNA^TM fluid control system (software)

TAZUNA^TM reduces the electric power cost further by approximately 20%.
TM The pressure and flow rate are automatically adjusted.

Model Numbering System

Motor Capacity	750 : 0.75 kW
	1500 : 1.5 kW
Motor Typed	Standard motor	A3 AC 200/200/220/230 V 50/60/60/60 Hz 3 phase electric induction motor(IE3) with CE marking
	Local Motor	AE: supplied by NOP Deutschl and (Germany) AF: supplied by NOP Taiwan AJ: supplied by NOP Asia (China) AK: supplied by NOP India

For further details about the local motor, please contact to our overseas branch or subsidiaries.

Rotor Capacity

	T208: Trochoid TM pump, 8cc / rev
	T206: Trochoid TM pump, 16cc / rev
Filtering method	C : Double-cyclone type
Relief Valve	VD : External return type
Relief Pressure setting	20 : 2.0 MPa
Relief Pressure setting	15 : 1.5 MPa

Specification:

Item Model	Motor Capacity (kW)	Flow Rate (& min) 50 Hz/ 60 Hz	Maximum Pressure (MPa)	Approximate weight (kg)
YTH750A3-T208CVD *	0.75	12.0 / 14.4	2.0	34
YTH1500A3-T216CVD *	1.5	24.0 / 28.2	2.0	39

Dimensional :

Item Model	L	B	C	W	Q	H	M	D	I(^o)	TB
YTH750A3-T208CVD *	599.7	235.7	206.7	175.7	20	364	253.5	170	30	151
YTH1500A3-T216CVD *	639.2	255.7	226.7	195.7	40	383.5	273	202	45	168

World's First - All-in-one, Medium-pressure Coolant Pump

This is a basic YTH model consolidating a large coolant system into one unit. Simply replace a conventional medium-pressure pump with YTH-CT to reduce the occupied space to 1/20th by volume. The saved space expands the available plant space, resulting in a higher production efficiency.

Maximum operating pressure: 2.0 MPa
Maximum flow rate: 28.8 liters/min
No suction filter is required
No clean tank is required
Applicable only to continuous running (intermittent running is not applicable)
No transfer pump is required on the coolant tank end
No plumbing is required to interconnect various components

Double-cyclone Filter

A proprietary double-cyclone system removes chips. The first cyclone removes larger debris, while the second cyclones remove smaller particles. The line-filter cleaning cycle is extended by 24 times.

Chips larger than 20m in size is removed (when using water-soluble coolant fluid).

Compatible types of chips :

Material	Iron	Casting	Aluminium	Copper
Compatibility	Excellent	Excellent	Good	Excellent

No liquid containing abrasive stone/grain is allowed
Please contact us for the use of High Silicon Aluminum

Filtering Performance :

Suction Strainer	3mm (Solids larger than this must be removed in the tank)
Filter	50 m: 95% (specific gravity 2.7) 100 m: 99% (specific gravity 2.7)

High-efficiency Trochoid^TM Pump

YTH-CT uses a Trochoid^TM pump which excels in fluid control efficiency. The double-cyclone system sorts out chips and enables direct connection to the coolant tank.

Compatible types of fluid

Water-soluble coolant fluid
Not for water-insoluble coolant fluid, lubricant oil or fuel oil
Not for clear water, purified water, aqueous solutions and viscous fluids without rust-preventive property, corrosive liquid, solvents, and oils
Relief valve is built into the unit.

Huge Energy Saving Effect Reduces Utility Costs

The use of YTH-CT results in huge energy savings over the conventional centrifugal pumps. The electric power cost is greatly reduced.

Operating cycle: total 80 seconds cycle

Unload (0MPa) 20 sec. Coolant through (1.1 MPa) 20 sec.
Unload (0MPa) 20 sec. Coolant through (1.1 MPa) 20 sec.

The calculation is based on operation 8hours/day, 365days/year, and the electric power billed at 20/kWh.

Results may differ according to the conventional pump specifications and the machining conditions reference data

Series name	C SERIES CT (Specification : Double cyclone filter + TrochoidTM pump)		C SERIES CI (Specification: Cyclone filter + Impeller pump)
Specifications for pump proper
Pump model	T208 50Hz / 60Hz	T216 50Hz / 60Hz	I155	I152	I305	I302
Flow rate (l /min)	12.0 / 14.4	24.0 / 28.8	150 (Maximum)		300 (Maximum)
Compatible fluid	Water-soluble coolant fluid
Maximum allowable viscosity (mm²/s) (Filtering performance)	22		2
Liquid temperature range (^oC)	-5 -60
Rotational speed (r/min)	1500 / 1800		3000	3600	3000	3600
Maximum pressure (MPa)	2.0		-
Total pump head (m)	-		55	40	65	45
Filter type	Cyclone x 2 stages		Cyclone x 1 stage
Filtering performance	100m: 99.9~ 50 m: 95% (Silica sand: specific gravity2.7)
Contaminant drain port flow rate (l/min)	30~40 (Pressure 0.02MPa)		20~35 (Pressure 0.02MPa)	25~40 (Pressure 0.02MPa)	45~60 (Pressure 0.02MPa)	50~70 (Pressure 0.02MPa)
Remarks	Install a plate filter of #18 or finer mesh on the suction end of the tank.
Painted color of the pump section	Flat black (Approximately Munsell N1.0)
Approximate weight (kg)	16		23		34	33
Relief valve specifications
Type	External return type		-
Relief pressure setting (MPa)	2.0 / 1.5		-
Motor specifications*1
Model No.	750A3	1500A3	1500AC		3700AC
Specifications	3-phase, squirrel-cage induction motor, totally enclosed, external fan, flange-mounting configuration
Output (kW)	0.75	1.5	1.5		3.7
Voltage (V)	200/200/220/230	200/200/220/230	200/200/220/230		200/200/220/230
Frequency (Hz)	50/60/60/60	50/60/60/60	50/60/60/60		50/60/60/60
Rotational speed (r/min)	1440/1730/1745/1745	1445/1740/1750/1755	2890/3460/3485/3495		2910/3490/3515/3525
Rating	S1
Current (A)	3.80/3.40/3.40/3.40	6.80/6.40/6.00/6.00	6.00/5.80/5.40/5.20		13.6/13.2/12.2/11.8
Number of phases	3
Number of poles	4P		2P
Insulation class	F
Approximate weight (kg)	18	23	20		36
Protection rating	IP55
Efficiency class	IE3
Compliance CE	0

Efficient Cooling Performance

This coolant unit leverages advanced air-cooled technology combined with a closed impeller to provide efficient coolant circulation. Its 8-meter head size and maximum suction of 2 meters enable stable operation even in demanding machine tasks, safeguarding equipment longevity and operational consistency.

Robust and Reliable Construction

Engineered for longevity, the NOP Coolant Unit CT uses high-quality cast iron and stainless steel, meeting ISO 9001:2015 standards. Its epoxy-coated exterior provides added corrosion resistance, while the mechanical seal prevents leaks, ensuring up to 10,000 hours of reliable service with minimal maintenance.

Designed for Versatility

With manual control, horizontal mounting, and compatibility with 220V/380V electric power, this unit is adaptable to various industrial environments. Its compact profile (260 x 175 x 220 mm) and lightweight design (7.5 kg) make installation easy in limited spaces, supporting a range of engineering applications.

FAQs of NOP Coolant Unit CT:

Q: How is the NOP Coolant Unit CT typically installed and operated?

A: The unit is designed for horizontal mounting and is manually controlled, making installation straightforward. Simply connect the inlet (1/2 inch BSP) and outlet, ensure proper power connection (220V/380V, 50 Hz), and initiate operation as required for your coolant circulation needs.

Q: What kind of machines is this coolant unit suitable for?

A: The NOP Coolant Unit CT is ideal for CNC machines, lathes, and milling machines. Its robust construction and centrifugal pump theory make it well-suited for demanding industrial coolant circulation applications.

Q: When should I consider replacing the coolant unit?

A: With a typical lifespan of 10,000 hours, replacement is recommended when consistent performance drops, noise increases above 60 dB, or if there is evidence of seal wear or reduced flow rates despite regular maintenance.

Q: Where should I use this unit to achieve maximum efficiency?

A: Place the unit in well-ventilated workshop areas near or beside your CNC or lathe machine. Its side suction and self-priming features allow it to be positioned close to coolant tanks for efficient operation, even in compact spaces.

Q: What maintenance process does the coolant unit require?

A: Routine inspection of the mechanical seal, checking for leakage, and cleaning the impeller are recommended. Given its low maintenance design, periodic visual checks and ensuring no blockages in inlet/outlet connections typically suffice.

Q: How does the closed impeller and mechanical seal benefit operation?

A: The closed impeller design reduces the risk of clogging and enhances flow efficiency, while the mechanical seal offers superior leak protection, extending the operating life and minimizing downtime due to maintenance.

Q: What makes this coolant pump advantageous compared to alternatives?

A: Key benefits include its corrosion-resistant, epoxy-coated body, long operational life (up to 10,000 hours), low noise output, capacity to operate over a wide temperature range (-10C to +100C), and compliance with ISO 9001:2015 quality standards, ensuring reliability and safety.
